KNX products from Insta

KNX products from Insta have been an integral part of smart building automation for years. As a white label OEM manufacturer, we offer you the opportunity to offer high-quality and innovative KNX products such as actuators, sensors, and system products under your brand label, thereby expanding your portfolio in a sustainable manner.

KNX

Power supply 160 mA

Power supply 160 mA

Referenznummer: 60031023

Supplying KNX devices with bus voltage
Supplying additional devices with direct current
Mounting on DIN rail according to DIN EN 60715 in sub-distribution unit

Power supply 320 mA

Power supply 320 mA

Referenznummer: 60032023

Supplying KNX devices with bus voltage
Supplying additional devices with direct current
Mounting on DIN rail according to DIN EN 60715 in sub-distribution unit

Power supply 640 mA

Power supply 640 mA

Referenznummer: 60033023

Supplying KNX devices with bus voltage
Supplying additional devices with direct current
Mounting on DIN rail according to DIN EN 60715 in sub-distribution unit

Power supply 1280 mA

Power supply 1280 mA

Referenznummer: 60034023

Supplying KNX devices with bus voltage
Supplying additional devices with direct current
Mounting on DIN rail according to DIN EN 60715 in sub-distribution unit

KNX TP-Coupler

KNX TP-Coupler

Referenznummer: 60172020

Connects two KNX lines/segments/areas with each other in terms of data and ensures electrical isolation between these lines/segments/areas
Can be operated as an area coupler, line coupler, segment coupler or amplifier by addressing
Installation in small distribution boards on top-hat rail in accordance with IEC 60715

KNX Heating actuator 6gang with controller

KNX Heating actuator 6gang with controller

Referenznummer: 63394021

Switching of electrothermal valve drives for heaters or cooling ceilings
Operation in KNX system
Installation in sub-distribution units on DIN rail according to DIN EN 60715

KNX Dimming actuator 4gang Secure Comfort

KNX Dimming actuator 4gang Secure Comfort

Referenznummer: 63961023

Actuator for switching and dimming of incandescent lamps, HV halogen lamps, dimmable HV LED lamps (minimum load=1W), dimmable compact fluorescent lamps, dimmable inductive transformers with LV halogen or LV LED lamps, dimmable electronic transformers with LV halogen or LV LED lamps.
Operating in KNX systems
Mounting on DIN rail according to DIN EN 60715 in sub-distribution unit

KNX Push-button interface 2gang Standard

KNX Push-button interface 2gang Standard

Referenznummer: 64091021

Inputs for polling of conventional, potential-free contacts in KNX systems and for sending telegrams to the KNX bus for signalling of statuses, meter readings, operation of loads, etc.
Outputs for activation of LEDs
Mounting in appliance box with dimensions according to DIN 49073 in combination with a suitable cover
When mounting behind switch inserts and push-button inserts, use an appliance box with sufficient installation depth

KNX Push-button interface 2gang Comfort

KNX Push-button interface 2gang Comfort

Referenznummer: 64091026

Inputs for polling of conventional, potential-free contacts in KNX systems and for sending telegrams to the KNX bus for signalling of statuses, meter readings, operation of loads, etc.
Outputs for activation of LEDs
Mounting in appliance box with dimensions according to DIN 49073 in combination with a suitable cover
When mounting behind switch inserts and push-button inserts, use an appliance box with sufficient installation depth

KNX Push-button interface 4gang Standard

KNX Push-button interface 4gang Standard

Referenznummer: 64101021

Inputs for polling of conventional, potential-free contacts in KNX systems and for sending telegrams to the KNX bus for signalling of statuses, meter readings, operation of loads, etc.
Outputs for activation of LEDs
Mounting in appliance box with dimensions according to DIN 49073 in combination with a suitable cover
When mounting behind switch inserts and push-button inserts, use an appliance box with sufficient installation depth

KNX Push-button interface 4gang Comfort

KNX Push-button interface 4gang Comfort

Referenznummer: 64101026

Inputs for polling of conventional, potential-free contacts in KNX systems and for sending telegrams to the KNX bus for signalling of statuses, meter readings, operation of loads, etc.
Outputs for activation of LEDs
Mounting in appliance box with dimensions according to DIN 49073 in combination with a suitable cover
When mounting behind switch inserts and push-button inserts, use an appliance box with sufficient installation depth

KNX Push-button interface 8gang Standard

KNX Push-button interface 8gang Standard

Referenznummer: 64201021

Inputs for polling of conventional, potential-free contacts in KNX systems and for sending telegrams to the KNX bus for signalling of statuses, meter readings, operation of loads, etc.
Outputs for activation of LEDs
Mounting in appliance box with dimensions according to DIN 49073 in combination with a suitable cover
When mounting behind switch inserts and push-button inserts, use an appliance box with sufficient installation depth

KNX Push-button interface 8gang Comfort

KNX Push-button interface 8gang Comfort

Referenznummer: 64201026

Inputs for polling of conventional, potential-free contacts in KNX systems and for sending telegrams to the KNX bus for signalling of statuses, meter readings, operation of loads, etc.
Outputs for activation of LEDs
Mounting in appliance box with dimensions according to DIN 49073 in combination with a suitable cover
When mounting behind switch inserts and push-button inserts, use an appliance box with sufficient installation depth

KNX USB data interface

KNX USB data interface

Referenznummer: 64492021

Connecting PCs to KNX systems
Addressing, programming and diagnostics of KNX devices
Compatible with KNX Data-Secure products
Support of long frames for ETS5/6
FM device: Mounting in appliance box according to DIN 49073
RMD device: Installation in small distributor board on DIN rail according to DIN EN 60715

KNX DALI-2 Gateway 2gang

KNX DALI-2 Gateway 2gang

Referenznummer: 64545022

Controlling of luminaires and other applications with DALI operating device in KNX installations, e.g. electronic ballast
Integration of DALI-2 sensors possible
Mounting on DIN rail according to EN 60715 in distribution boxes

KNX DALI-2 Gateway 2gang Secure

KNX DALI-2 Gateway 2gang Secure

Referenznummer: 64546022

Controlling of luminaires and other applications with DALI operating device in KNX installations, e.g. electronic ballast
Integration of DALI-2 sensors possible
Mounting on DIN rail according to EN 60715 in distribution boxes

KNX DALI-2 Actuator 4gang Secure RMD

KNX DALI-2 Actuator 4gang Secure RMD

Referenznummer: 64547021

Controlling of luminaires and other applications with DALI operating device in KNX installations, e.g. electronic ballast
Mounting on DIN rail according to EN 60715 in distribution boxes
Simple configuration without DALI commissioning - DALI Plug&Play
